1-770872-0,709-9921,TE Connectivity Mini-Universal Mate-N-Lok 系列 2路 4.14mm节距 (1排) 直 PCB 针座 1-770872-0, 焊接端接, 9.5A, 通孔 ,TE Connectivity
微型通用 MATE-N-LOK 垂直安装印刷电路板引脚针座，具有 4.14mm 中心线，用于预装了镀锡或镀金引脚触点的线到板应用。 这些微型通用 MATE-N-LOK 垂直安装印刷电路板引脚针座具有白色 UL94V-0 尼龙外壳，包含正向锁定闩锁机制，可确保牢固配接和锁定板，利于固定印刷电路板，带或不带排放孔。 有关配接连接器，请参见微型通用 MATE-N-LOK 插头外壳和微型通用 MATE-N-LOK 2 插头外壳（均使用插座触点）
部件号 X-770166-X、X-770170-X、X-770174-X、X-770178-X、X-770182-X、X-770186-X、X-770190-X、X-770743-X、X-794065-X、X-794066-X、X-794067-X、X-794068-X、X-794070-X 和 X-794072-X 全部具有排放孔。
| Additional Data | |||||
| RS Stock Number | Manufacturer Part Number | Housing Style | Drain Holes | Contact Plating | Width |
| 500-604 | 1-770166-0 | In-Line | Yes | Tin | 9.83 mm |
| 500-585 | 1-770166-1 | In-Line | Yes | Duplex | 9.83 mm |
| 500-597 | 1-770170-0 | In-Line | Yes | Tin | 13.97 mm |
| 500-581 | 1-770170-1 | In-Line | Yes | Duplex | 13.97 mm |
| 500-614 | 1-770174-0 | Dual Row | Yes | Tin | 9.83 mm |
| 500-591 | 1-770174-1 | Dual Row | Yes | Duplex | 9.83 mm |
| 500-632 | 1-770178-0 | Dual Row | Yes | Tin | 13.97 mm |
| 500-496 | 1-770182-0 | Matrix | Yes | Tin | 14 mm |
| 500-468 | 1-770182-1 | Matrix | Yes | Duplex | 14 mm |
| 500-430 | 1-770186-0 | Matrix | Yes | Tin | 18.11 mm |
| 500-440 | 1-770186-1 | Matrix | Yes | Duplex | 18.11 mm |
| 500-626 | 1-770190-0 | Matrix | Yes | Tin | 22.28 mm |
| 500-610 | 1-770190-1 | Matrix | Yes | Duplex | 22.28 mm |
| 720-2297 | 1-770621-0 | Dual Row | No | Tin | 26.39 mm |
| 680-1363 | 1-770743-0 | Dual Row | Yes | Tin | 22.28 mm |
| 709-9915 | 1-770743-1 | Dual Row | Yes | Duplex | 22.28 mm |
| 709-9921 | 1-770872-0 | In-Line | No | Tin | 9.83 mm |
| 709-9931 | 1-770873-0 | In-Line | No | Tin | 13.97 mm |
| 756-1234 | 1-770873-1 | In-Line | No | Duplex | 13.97 mm |
| 680-1367 | 1-770874-0 | Dual Row | No | Tin | 9.83 mm |
| 756-1243 | 1-770874-1 | Dual Row | No | Duplex | 9.83 mm |
| 709-9956 | 1-770875-0 | Dual Row | No | Tin | 13.97 mm |
| 720-2294 | 1-770875-1 | Dual Row | No | Duplex | 13.97 mm |
| 500-676 | 1-794065-0 | Dual Row | Yes | Tin | 18.11 mm |
| 500-490 | 1-794065-1 | Dual Row | Yes | Duplex | 18.11 mm |
| 680-1411 | 1-794066-0 | Dual Row | Yes | Tin | 26.39 mm |
| 680-1414 | 1-794067-0 | Dual Row | Yes | Tin | 30.53 mm |
| 680-1418 | 1-794068-0 | Dual Row | Yes | Tin | 34.67 mm |
| 500-620 | 1-794070-0 | Dual Row | Yes | Tin | 42.95 mm |
| 500-636 | 1-794070-1 | Dual Row | Yes | Duplex | 42.95 mm |
| 680-1427 | 1-794072-0 | Dual Row | Yes | Tin | 51.23 mm |
| 720-2307 | 1-794073-0 | Dual Row | No | Tin | 18.11 mm |
| 720-2304 | 1-794073-1 | Dual Row | No | Duplex | 18.11 mm |
| 尺寸 | ||
| 电路数量 | 尺寸 (mm) | |
| A | B | |
| 2 | 9.8 | 5.6 |
| 3 | 14 | 5.6 |
| 4 | 9.8 | 9.8 |
| 6 | 14 | 9.8 |
| 8 | 18 | 9.8 |
| 9 | 14 | 14 |
| 12 | 18.1 | 14 |
| 15 | 22.3 | 14 |
| 20 | 43 | 9.8 |
|
|
|
|
|
|
