200389-2,680-9058,TE Connectivity M 系列 导针 200389-2 ,TE Connectivity
M 系列导向引脚和插座由不锈钢制成。 这些导向引脚和插座用于在配接期间对齐连接器两半部分。 中心导向引脚和插座用于具有单安装孔的外壳以及具有 3 或 4 个安装孔的外壳的中心孔。 角导向引脚和插座用于具有 2 至 4 个安装孔的外壳的角孔，但不能用于中心安装孔。
| Technical Specification | |||
| RS Stock Number | Manufacturer Part Number | Type | Suitable Connector (No. of Positions) |
| 680-9058 | 200389-2 | Centre Pin | Standard: 6, 14, 20, 26, 34, 41, 50, 75, 104 Posted: 6, 14, 20, 26, 34, 41, 50, 75, 104 |
| 680-9052 | 200390-9 | Centre Socket | Standard: 6, 14, 20, 26, 34, 41, 50, 75, 104 Posted: 6, 14, 20, 26, 34, 41, 50, 75, 104 |
| 718-6732 | 1-200833-1 | Corner Pin | Standard: 34, 50 Posted: 34, 50 |
| 718-6741 | 1-200835-1 | Corner Socket | Standard: 34, 50 Posted: 34, 50 |
| 709-9874 | 201046-2 | Corner Pin | Standard: 75, 104, 160 CF Posted: 75, 104, 160 CF |
| 718-6760 | 1-201046-2 | Corner Pin | Standard: 75, 104, 160 CF Posted: 75, 104, 160 CF |
| 709-9883 | 201047-2 | Corner Socket | Standard: 75, 104, 160 CF Posted: 75, 104, 160 CF |
| 745-5983 | 202512-1 | Corner Socket | - |
| 782-6143 | 201046-7 | Corner Pin | Standard: 75, 104, 160 CF Posted: 75, 104, 160 CF |
| 782-6247 | 202174-5 | Corner Socket | Standard: 104 CF Posted: 104 CF |
|
|
|
|
|
